The product is compatible with voltages ranging from 600 to 1000 volts and rated currents between 20 and 40 amps, making it ideal for residential and small commercial PV systems. The conductors, crafted from high-purity copper, ensure low contact resistance and efficient power transmission. The casing, crafted from fire-resistant, high-temperature resistant, and UV-resistant materials, achieves an IP67 protection rating, ensuring safety in rain, dust, and outdoor settings. The product's compact design eases wiring and installation.
The Solar Cable Connector with UL Listing ensures a reliable power connection for solar modules, supporting the efficient performance of photovoltaic systems. The waterproof and sealed design guarantees long-term safety and reliability in outdoor settings. The quick-plug design aids in the installation, maintenance, and replacement of photovoltaic systems, making it ideal for residential and small commercial solar wiring.
The product is made from fire-resistant engineering plastics, offering a strong and durable structure that withstands high temperatures and UV radiation. The low impedance of copper conductors ensures efficient power transmission. The waterproof and sealed design prolongs its service life. OEM customization and export packaging are available to meet international market demands, supporting sales by wholesalers and cross-border e-commerce.
Appropriate for residential rooftop photovoltaic systems, small-scale photovoltaic stations, outdoor mobile photovoltaic devices, and diverse solar applications. The Solar Cable Connector with UL Listing ensures a secure and dependable power connection for solar modules, supporting the long-term stability of photovoltaic systems. Professional export packaging ensures safe transportation, aiding sales by overseas wholesalers, distributors, and cross-border e-commerce.
| Connector system | MC4 CONNECTING | Insulation material | PC |
| Rated current | Certitied by 30A | Locking system plug connectors | Snap-in (nur/only MC4) |
| Rated voltage | 1000V DC (IEC) | Flame class | UL94-HB / UL94-V0 |
| Ambient temperature range | -40°C...+90°C (IEC)-40°C...+40°C (UL) | Safety class | II |
| Degree of protection, matedunmated | IP67IP2X | Contact system | MC Multilam |
| Contact resistance of plug connectors | 0,5mΩ | Type of termination Crimpen | Crimping |
| Contact material | Copper, tin plated | Cable Size | 2.5mm2, 4mm2, 6mm2 |
| Insertion Force /With Draw Force | <50N/>50N | Warranty | 25 years |
